2026 Ranger Diesel HD EPS ADC
THE EVERYDAY WORKHORSE
Polaris RANGER DIESEL HD EPS ABC For Sale South Lismore
Review Polaris RANGER DIESEL HD EPS ABC Specifications, Features & Colours Available at Farm Moto Polaris
Book a Test Ride
Schedule your Polaris test ride today at Farm Moto Polaris.
Available Colours
SAGE GREEN
- New GEN 2 Transmission - 50% Easier Shifting
- New High Output EPS – Enhanced responsiveness and slow speed maneuverability
- New 27” Pro Armor X Terrain Tires with Variable Tread Pattern for Reduced Cab Noise
- 24 HP Kubota Engine
- Industry best Donaldson air filter
- Sealed bearings and bushings
- Heavy-duty steering rack
- 2-piece sealed CV drive shaft
- Mud Guards
- Easy-Access Radiator Panel
- Tough, One-Piece Chassis
Get a Quote
Farm Moto Polaris – where your quote is just a click away.
RANGER DIESEL FEATURES
PERFORMANCE
- 140 Amps Charging System
- 65 kmph Top Speed
- 1134 kg Towing Capacity
- 720 kg Payload Capacity
- 2.5 cm DEEPER BOX
- 43.5 L
- True On-Demand AWD
- EPS, EBS, ADC
REFINEMENT
- Digital Gauge
- Thicker Seat Cushioning - Added 2.5 cm of padding
- More Leg Room for Getting In/Out
- 17% More Storage - 2 Glove Boxes and 6 Cup Holders
- Flip-Up Passenger Seat
A WHOLE NEW KIND OF RANGER TOUGH
33 cm Ground Clearance. 27" Tyres. 27.9 cm Usable Travel.
The RANGER Diesel is tougher and more reliable than ever.
GREAT FOR WORK
Get more done in a day with RANGER DIESEL. Its Kubota 3 cylinder engine delivers power and performance to help you get the job done.
RELIABILITY & DURABILITY∶ BUILT FOR THE HEAVY-DUTY LONG HAUL
The new RANGER Diesel is made to perform to the highest standards for years to come.
- Industry best Donaldson air filter
- 2-piece CV sealed system
- New mud guards
PERFORMANCE∶ CAPABLE ONLY SCRATCHES THE SURFACE
Featuring an unrivaled amount of towing capacity (1134 kg), payload capacity (719 kg) and ground clearance (33 cm), it’s always in a position to make work happen.
REFINEMENT∶ NEW STYLING. MORE STORAGE. MORE COMFORT.
With over 200 engineered accessories, added seat cushioning, and 17% more storage, you're able to customize and elevate every ride with the new RANGER Diesel.
Request a Brochure
Discover the model — request your brochure today at Farm Moto Polaris!
Technical Data
Cooling
Liquid
Cylinders-Displacement (cc)
898cc
Drive System Type
On-Demand True AWD / 2WD / Versatrac Turf Mode. Active Descent Control (ADC) and HD features including upgraded rear driveshaft, grease nipples, HD sway bar, sealed suspensions bushings, sealed ball joints and driveshaft spline seals.
Motor
Kubota 3-Cylinder Diesel
Fuel System/Battery
Mechanical injection
Horsepower
24.8 HP
Transmission / Final Drive
Automatic PVT H / L / N / R / P; Shaft
Bed Box Dimensions (L x W x H)
93.3 x 137.8 x 31.75 cm
Front / Rear Rack or Box Capacity
435 kg
Estimated Dry Weight
766 kg
Fuel Capacity
43.5 L
Ground Clearance
33 cm
Hitch Towing Rating
1134 kg
Hitch Type
Receiver w/ ECE R55 ball
Overall Vehicle Size (L x W x H)
305 x 158 x 196 cm
Payload capacity
720 kg
Person Capacity
3
Wheelbase
206 cm
Front Suspension
Dual A-Arm with Stabilizer Bar 27.9 cm Travel
Rear Suspension
Dual A-Arm IRS with Stabilizer Bar 27.9 cm Travel
Front/Rear Brakes
Hydraulic Disc
Parking Brake
Hand-Actuated
Front Tyres
27 x 9-14; Pro Armor X Terrain with Variable Tread Pattern
Rear Tyres
27 x 11-14; Pro Armor X Terrain with Variable Tread Pattern
Wheels
14" Alloy
Driver Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Trip Meters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm, Horn, Backup Alarm
Electronic Power Steering
Standard
Lighting
LED headlights & taillights with integrated turn signals
Cargo System
Lock & Ride®
Variant
Homologated Tractor
